Page : 1 of 4
No.: F00024290-Ver.2
Chimei Innolux Corporation
No.3, Sec.1, Huansi Road, Tainan County,
Southern Taiwan Science Park 74147,
Taiwan
Subject : Lamp Assembly Disassembly order
Model : M185B1-L07
1. Separate the pcb protector film from the module
2.Remove 3 pcs screws.
3. Release the hooks around the module for remove the front metal frame
4. Separate the isolated film from the metal rear
PCB protector film
Isolated film
