Description Spare part number
●
Ruby red 701677-001
●
Sparkling black 701678-001
●
Winter blue 709169-001
Display Hinge Kit (includes left and right display hinges and brackets)
701683-001
Webcam/microphone module
707767-001
1.
If it is necessary to replace the webcam/microphone module:
a.
Detach and release the webcam/microphone module as far as the webcam/microphone
module cable allows. (The webcam/microphone module is attached to the display enclosure
with double-sided tape.)
b.
Disconnect the webcam/microphone cable (1) from the webcam/microphone module.
c.
Remove the webcam/microphone module (2).
Component replacement procedures
85
