11. Remove the display bezel (3). Display bezels are available using the spare part numbers
447998-001 (for dual lamp display assemblies) and 447997-001 (for single lamp display
assemblies).
NOTE: See Camera module on page 48 for camera module replacement instructions. See Display
inverter on page 50 for display inverter replacement instructions.
12. If it is necessary to replace the display panel, remove the four Phillips PM2.5×8.0 screws (1) and
the two Phillips PM2.5×6.0 screws (2) that secure the display panel to the display enclosure.
13. Remove the display panel (3). Display panels are available using the following spare part
numbers:
●
447988-001 (17.0-inch, WXGA+, TFT, dual lamp, BrightView display assembly)
●
447987-001 (17.0-inch, SXGA+, TFT, single lamp, BrightView display assembly)
●
447986-001 (17.0-inch, WXGA+, TFT, single lamp, BrightView display assembly)
14. If it is necessary to replace the display hinges, remove the two Phillips PM2.0×3.0 screws (1) that
secure each display hinge to the display panel.
15. Remove the display hinges (2).
72 Chapter 4 Removal and replacement procedures

HP Pavilion DV9500 Specifications

General

Processor	Intel Core 2 Duo
RAM	Up to 4 GB DDR2 SDRAM (configurable)
Storage	160GB or 250GB SATA HDD
Optical Drive	DVD±RW with Double Layer Support
Operating System	Windows Vista
Chipset	Intel PM965 Express
Hard Drive	160GB or 250GB SATA HDD
Wireless	802.11b/g
Ports	1 x HDMI, 1 x VGA, 1 x IEEE 1394 (FireWire), 1 x Headphone, 1 x Microphone
Weight	3.4 kg (7.5 lbs)
