Item Component Spare part number
●
For use in Turkey 836099-141
●
For use in the United Kingdom 836099-031
●
For use in the United States 836099-001
(3) Optical Drive Cable Kit 811199-001
(4) Touchpad 813987-001
(5) Power button board (includes cable)
For use in all models except Star Wars Special Edition models 809033-001
For use in Star Wars Special Edition models 837611-001
(6) Hard drive (does not include bracket):
NOTE: The hard drive bracket and connector are available using spare part number 809296-001.
2-TB, 5400-rpm, 2.5-inch 801808-005
1-TB, 5400-rpm, 2.5-inch, hybrid 8 GB SSD 731999-005
1-TB, 5400-rpm, 2.5-inch 778192-005
750 GB, 5400 rpm hard drive, 2.5 inch 778190-005
500-GB, 5400-rpm, 7 mm, hybrid 8 GB SSD 732000-005
500-GB, 5400-rpm, 2.5 inch 778188-005
M.2 solid-state drive (not illustrated)
256 GB solid-state drive (SSD), M.2, TLC 837768-001
(7) USB board (includes cable)
For use in all models except Star Wars Special Edition models 809038-001
For use in Star Wars Special Edition models 837612-001
(8) System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-501: Windows 8.1 Standard operating system
xxxxxx-601: Windows 8.1 Professional or Windows 10 operating system
For use in models with discrete graphics (NVIDIA N16S-GT (GeForce 940M)):
●
Intel Core i7-6500U processor and 4 GB of dedicated video memory 830603-001, -601
●
Intel Core i7-6500U processor and 2 GB of dedicated video memory (for use in Star
Wars Special Edition models)
836093-001, -601
●
Intel Core i5-6200U processor and 4 GB of dedicated video memory 830602-001, -601
●
Intel Core i5-6200U processor and 2 GB of dedicated video memory 830601-001, -601
●
Intel Core i5-6200U processor and 4 GB of dedicated video memory (for use in Star
Wars Special Edition models)
836095-001, -601
Computer major components 25
