4. Remove the three broadhead Phillips PM2.0×2.0 screws (2) that secure the TouchPad to the computer.
5. Lift the bottom of touchpad up, and then pull it away from computer.(3).
NOTE: When installing the TouchPad, note that the metal protrusion that extents from the touchpad is
installed UNDER the keyboard shield (4).
Reverse this procedure to install the touchpad.
