Rear of printer
1 USB port: Use this port to connect the printer to a computer or to an HP direct-printing digital
camera using a USB cable.
2 Power cord connection: Connect the power cord here.
Inside front of printer
1 Input tray: Load paper here.
2 Input tray extension: Pull out to support paper.
3 Paper-width guide: Move to the width of the current paper to position the paper properly.
4 Camera port: Connect a PictBridge digital camera, the optional HP Bluetooth wireless printer
adapter, or an HP iPod.
5 Memory card slots: Insert memory cards into these slots. See Get photos from a memory
card. Some models may not support all types of memory cards.
6 Print cartridge door: Open to insert or remove a print cartridge. See Replace the print
cartridge.
7 Output tray (open): The printer deposits printed photos here.
HP Photosmart A510 series User Guide 5
