HP ProBook 4420s Specification

Digital Persona Pro AD: Designed for the enterprise customer. Integrates with Active Directory and
gives IT Managers the ability to provision users, create login policies based on passwords,
biometrics or smartcards. Management features also include remote credential recovery in case
the user forgets the password, loses the smartcard or cannot use the fingerprint reader for any
reason. In addition, advanced auditing capabilities are also built in. Digital Persona Pro AD is
available now.
Digital Persona Pro Workgroup: Designed for the small business customer. Provides features
similar to the Active Directory version, but for workgroups. Workgroup activation is built into HP
ProtectTools, and activation of up to 5 seats is completely free.
Power Supply
Power SupplyPower Supply
Power Supply Models with integrated graphics: External 65-watt Smart AC adapter
External 90-watt Smart AC adapter
6-foot (1.8-meter) power cord included; total length including external AC adapter is 12 feet (3.66
meter)
HP Fast Charge *
* HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast
Charge does not apply to the HP 9-cell battery.
Battery
BatteryBattery
Battery Primary battery
Primary batteryPrimary battery
Primary battery HP 9-cell (93 WHr) Li-Ion battery
HP 6-cell (47 WHr) Li-Ion battery
Battery Life
Battery LifeBattery Life
Battery Life Configurations with integrated graphics
Configurations with integrated graphicsConfigurations with integrated graphics
Configurations with integrated graphics
HP ProBook 4320s
HP ProBook 4320sHP ProBook 4320s
HP ProBook 4320s
9-cell battery
9-cell battery9-cell battery
9-cell battery Up to 10 hours
6-cell battery
6-cell battery6-cell battery
6-cell battery Up to 5 hours
HP ProBook 4420s
HP ProBook 4420sHP ProBook 4420s
HP ProBook 4420s
9-cell battery
9-cell battery9-cell battery
9-cell battery Up to 10 hours
6-cell battery
6-cell battery6-cell battery
6-cell battery Up to 4 hours and 30 minutes
NOTE:
NOTE:NOTE:
NOTE: Battery life will vary depending on the product model, configuration, loaded applications,
features, use, wireless functionality and power management settings. The maximum capacity of the
battery will naturally decrease with time and usage. See MobileMark07 battery benchmark
www.bapco.com/products/mobilemark2007 for additional details.
System Standby Time
System Standby TimeSystem Standby Time
System Standby Time Up to 1 week
Power Conservation
Power ConservationPower Conservation
Power Conservation Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance
Mode, or Automatic mode)
ATI PowerPlay technology
Hibernation
Standby
ACPI compliance
QuickSpecs
HP ProBook 4320s Notebook PC
HP ProBook 4320s Notebook PCHP ProBook 4320s Notebook PC
HP ProBook 4320s Notebook PC
HP ProBook 4420s Notebook PC
HP ProBook 4420s Notebook PCHP ProBook 4420s Notebook PC
HP ProBook 4420s Notebook PC
Standard Features (availability may vary by country)
DA - 13568 North America — Version 10 — July 23, 2010 Page 10

HP ProBook 4420s Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-580M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Firewire (IEEE 1394) ports	0
Cable lock slot type	Kensington
AC adapter power	65 W
Battery capacity	47 Wh
Number of battery cells	6
Product color	Black
Country of origin	China
Pointing device	Touchpad
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor code	SLC29
Processor ARK ID	49652
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	232 mm
Width	336 mm
Height	27 mm
Weight	2140 g
