HP ProBook 4420s Specification

Graphics
GraphicsGraphics
Graphics Integrated graphics:
Intel HD Graphics
Microsoft DirectX 10.1 capable
Discrete graphics:
ATI Mobility Radeon HD 530v graphics controller with 512 MB dedicated video memory
ATI Mobility Radeon HD 5470 graphics controller with 512 MB dedicated video memory
Microsoft DirectX 11 capable
Display
DisplayDisplay
Display Internal
InternalInternal
Internal HP ProBook 4320s:
13.3-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
HP ProBook 4420s:
14.0-inch diagonal LED-backlit HD anti-glare (1366 x 768 resolution)
Optional HP Privacy Filter
External
ExternalExternal
External Up to 32-bit per pixel color depth
VGA
VGAVGA
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz.
HDMI
HDMIHDMI
HDMI port supports direct connection to high-definition displays with up to
1920 x 1080 resolution and 7-channel audio with one convenient cable (not
included).
NOTE:
NOTE:NOTE:
NOTE: Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard DDR3 PC3-8500 (1066 MHz) * or PC3-10600 (1333 MHz) * SDRAM
Two SODIMM slots supporting dual-channel memory
1024 MB, 2048 MB, and 4096 SODIMMs
Maximum
MaximumMaximum
Maximum Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel
Dual-channelDual-channel
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size
and speed in both memory slots.
* Memory speed is processor dependent.
NOTE:
NOTE:NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the
lower memory speed. Full availability of 4 GB or more of memory requires Windows Vista Business 64-
bit or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon
your configuration, so that above 3 GB all memory may not be available due to system resource
requirements.
QuickSpecs
HP ProBook 4320s Notebook PC
HP ProBook 4320s Notebook PCHP ProBook 4320s Notebook PC
HP ProBook 4320s Notebook PC
HP ProBook 4420s Notebook PC
HP ProBook 4420s Notebook PCHP ProBook 4420s Notebook PC
HP ProBook 4420s Notebook PC
Standard Features (availability may vary by country)
DA - 13568 North America — Version 10 — July 23, 2010 Page 5

HP ProBook 4420s Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-580M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Firewire (IEEE 1394) ports	0
Cable lock slot type	Kensington
AC adapter power	65 W
Battery capacity	47 Wh
Number of battery cells	6
Product color	Black
Country of origin	China
Pointing device	Touchpad
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor code	SLC29
Processor ARK ID	49652
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	232 mm
Width	336 mm
Height	27 mm
Weight	2140 g
