HP ProBook 4420s Specification

Keyboard
KeyboardKeyboard
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a
drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of
damage to sensitive components underneath. The 101/102-key compatible keyboard features a full-
pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys,
editing keys, both left and right control and alt keys, and 12 function keys. US and International key
layouts are available. Other features include hotkeys for instant access to power conservation and
brightness, and 19.05 x 19.05 mm key pitch (center-to-center spacing).
Pointing device
Pointing devicePointing device
Pointing device ClickPad with gestures support:
Two-finger scroll, zoom, pinch and pivot rotate
Expansion card slots
Expansion card slotsExpansion card slots
Expansion card slots ExpressCard/34 slot
ExpressCard/34 slotExpressCard/34 slot
ExpressCard/34 slot Supports ExpressCard/34 (34 mm x 75 mm x 5 mm) card sizes
Media Card Reader
Media Card ReaderMedia Card Reader
Media Card Reader Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,
Memory Stick Pro, Memory Stick Duo * , xD-Picture card
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card
directly into your notebook could damage the memory card and/or notebook.
Storage
StorageStorage
Storage Internal Storage Device
Internal Storage DeviceInternal Storage Device
Internal Storage Device 250/320/500 GB 7200 rpm SMART SATA II Hard Drive
640 GB 5400 rpm SMART SATA II Hard Drive
NOTE:
NOTE:NOTE:
NOTE: Up to 15 GB is reserved for the system recovery software.
HP 3D DriveGuard
HP 3D DriveGuardHP 3D DriveGuard
HP 3D DriveGuard
(Windows models only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Fixed optical drives
Fixed optical drivesFixed optical drives
Fixed optical drives Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive *
DVD+/-RW SuperMulti DL LightScribe Drive
* Support for the Blu-ray DVD drive on configurations with integrated
graphics requires Windows7 or Windows Vista; configurations with discrete
graphics support it with any offered Windows operating system.
QuickSpecs
HP ProBook 4320s Notebook PC
HP ProBook 4320s Notebook PCHP ProBook 4320s Notebook PC
HP ProBook 4320s Notebook PC
HP ProBook 4420s Notebook PC
HP ProBook 4420s Notebook PCHP ProBook 4420s Notebook PC
HP ProBook 4420s Notebook PC
Standard Features (availability may vary by country)
DA - 13568 North America — Version 10 — July 23, 2010 Page 7

HP ProBook 4420s Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-580M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Bluetooth version	2.0+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Firewire (IEEE 1394) ports	0
Cable lock slot type	Kensington
AC adapter power	65 W
Battery capacity	47 Wh
Number of battery cells	6
Product color	Black
Country of origin	China
Pointing device	Touchpad
Discrete graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Processor code	SLC29
Processor ARK ID	49652
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	232 mm
Width	336 mm
Height	27 mm
Weight	2140 g
