Component Description
(9)
USB 3.0 port Connects an optional USB device.
NOTE: Some models may show a slightly different icon.
(10)
USB 2.0 port Connects an optional USB device.
Right
Component Description
(1)
USB 2.0 ports (2) Connect optional USB devices.
(2)
RJ-11 (modem) jack (select models only) Connects a modem cable.
(3) Optical drive (select models only) Reads and writes (select models only) to an optical disc.
(4) Optical drive light Lights when the optical drive is active.
(5) Optical drive eject button Releases the optical drive disc tray.
16 Chapter 2 External component identification
