Speakers
Description Spare part number
Speakers 610831-001
Before removing the speakers, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 40).
5. Remove the following components:
a. Switch cover (see
Switch cover on page 51)
b. Keyboard (see
Keyboard on page 53)
c. Top cover (see
Top cover on page 56)
d. System board (see
System board on page 71)
Remove the speakers:
1. Position the computer right-side up with the front toward you.
2. Remove the two PM2.0×3.0 screws (1) that secure the speakers to the base enclosure.
3. Remove the speakers from the computer (2).
Reverse this procedure to install the speakers.
78 Chapter 4 Removal and replacement procedures
