HP ProBook 5330m Specification

Processors 2
nd
Generation Intel Core i5 Processors
Intel Core i5-2520M Processor (2.50 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W) *
Up to 3.20 GHz with Intel Turbo Boost Technology
2
nd
Generation Intel Core i3 Processors
Intel Core i3-2330M Processor (2.20 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W) * †
Intel Core i3-2310M Processor (2.10 GHz, 3 MB L3 cache, 2 cores/4 threads, 35W) * †
* Intel's numbering is not a measurement of higher performance.
† Not available with vPro.
NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in
battery optimization mode.
Operating System Preinstalled Genuine Windows 7 Professional 32 *
Genuine Windows 7 Professional 64 *
Genuine Windows 7 Home Premium 64 *
SUSE Linux Enterprise Desktop 11
FreeDOS
Supported Genuine Windows XP Professional 32
Certified SUSE Linux Enterprise Desktop 11
* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the
Windows 7 software and take full advantage of Windows 7 functionality.
See www.microsoft.com/windows/windows-7/ for details.
Chipset Mobile Intel QM67 Express Chipset
Intel Core i5 with vPro
technology capable
Intel Core i5 processor with vPro technology is a selectable feature that is available on units configured
with select processors, an Intel Centrino WLAN module, and a preinstalled Windows operating system. It
provides advances in remote manageability, security, energy-efficient performance, and wireless
connectivity. Intel Active Management Technology 7.0 (iAMT) offers built-in manageability and proactive
security for networked notebook PCs, even when they are powered off or when the operating system is
inoperable. * It can help identify threats before they reach the network, isolate infected systems, and
update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection to a power source,
and a direct (non-VPN) corporate network connection, which is either through a cable or a wireless LAN.
NOTE: Some functionality of Intel Core i5 processor with vPro technology, such as Intel Active
Management technology and Intel Virtualization technology, requires additional third-party software in
order to run. Availability of future "virtual appliances" applications for the Intel Core i5 processor with vPro
technology is dependent on third-party software providers. Compatibility with future "virtual appliances"
is yet to be determined.
Graphics Intel HD Graphics 3000
Microsoft® DirectX 10.1 (with Shader Model 4.1) and OpenGL 3.0 capable
QuickSpecs
HP ProBook 5330m Notebook PC
Standard Features
DA - 14018 North America — Version 9 — August 15, 2013 Page 4

HP ProBook 5330m Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Memory slots (available)	0
Pointing device	Touchpad
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Battery capacity	41 Wh
Battery life (max)	5.5 h
AC adapter power	65 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor code	SR04S
Processor ARK ID	52220
Processor package size	37.5 x 37.5 xrPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	225 mm
Width	328 mm
Height	25.2 mm
Weight	1820 g
