HP ProBook 5330m Specification

Display Internal 13.3 in. diagonal LED-backlit HD antiglare (1366 × 768 resolution)
HP Privacy Filter support
External Up to 32-bit per pixel color depth
VGA port supports resolutions up to 1600 x 1200 at 75 Hz, and lower
resolutions at up to 100 Hz
HDMI port supports direct connection to high-definition displays with up to
1920 x 1200 resolution and 7-channel audio with one convenient cable (not
included).
NOTE: Resolutions are dependent upon monitor capability, and resolution and
color depth settings.
Memory Standard PC3-10600 DDR3 SDRAM (1333 MHz) *
Two SODIMM slots supporting dual-channel memory
2 GB and 4 GB SODIMMs
Maximum Upgradable to 8 GB with 4 GB SODIMMs in slots 1 and 2
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and
speed in both memory slots.
* All memory modules operate at the maximum system supported speed of 1066 MHz.
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP
branded memory to ensure compatibility. Availability of 4 GB or more of memory requires a Windows 64-
bit operating system or Linux. With Windows 32-bit operating systems, memory above 3 GB may not all be
available due to system resource requirements.
Communications Integrated Intel 82579LM Gigabit * Network Connection
* The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for
Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission,
connection to a Gigabit Ethernet server and network infrastructure is required.
Wireless Devices Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support
for the latest industry standards. Mobile broadband (WWAN) requires a Windows operating system and is
available in select countries as a standard, factory-configurable feature or as an option to be added later.
Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the
supported wireless LAN and wireless WAN options.
Mobile Broadband
options
Two 850/900/1575/1700/1800/1900/2100 MHz antennas integrated in the
top of the display panel support current and future WWAN technologies.
NOTE: A separately purchased mobile network operator service is required.
HP hs2340 HSPA+ Mobile
Broadband module
Integrated mobile broadband module that provides connectivity to both HSPA
and HSPA+ (UMTS) networks. It also provides standalone, Internet and
network-assisted GPS functionality for various mapping applications and
security applications such as Computrace Pro for HP ProtectTools.
HP un2430 EV-DO/HSPA
Mobile Broadband module
Integrated mobile broadband module with Gobi global mobile Internet
technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA)
networks. It also provides GPS functionality for various mapping applications
and security applications such as Computrace LoJack Pro Premium for HP
ProtectTools.
QuickSpecs
HP ProBook 5330m Notebook PC
Standard Features
DA - 14018 North America — Version 9 — August 15, 2013 Page 5

HP ProBook 5330m Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-2300 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	13.3 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	1x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Memory slots (available)	0
Pointing device	Touchpad
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cable lock slot type	Kensington
Battery capacity	41 Wh
Battery life (max)	5.5 h
AC adapter power	65 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Processor code	SR04S
Processor ARK ID	52220
Processor package size	37.5 x 37.5 xrPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	225 mm
Width	328 mm
Height	25.2 mm
Weight	1820 g
