3. Disconnect all external devices from the computer.
4. Remove the battery (see Battery on page 56), and then remove the following components:
a. Service cover (see Service cover on page 57)
b. Hard drive (see Hard drive on page 58)
c. Optical drive (see Optical drive on page 69)
d. Keyboard (see Keyboard on page 72)
e. Base enclosure (see Base enclosure on page 82)
f. Fan and heat sink assembly (see Fan and heat sink assembly on page 79)
Remove the processor:
1. Use a Torx8 screw driver to turn the processor locking screw one-half turn counterclockwise (1), until
you hear a click.
2. Lift the processor (2) straight up, and remove it.
NOTE: The gold triangle (3) on the processor must be aligned with the triangle icon embossed on
the processor socket (4) when you install the processor.
Reverse this procedure to install the processor.
Processor 99
