5. Remove the WLAN and WWAN transceiver (1) and the hinge brackets (2).
The hinge bracket is available using spare part number 738699-001.
6. Remove the display panel cable and the wireless transceiver.
7. If it is necessary to replace the webcamera/microphone module or microphone module:
CAUTION: Handle the webcamera/microphone module and microphone module with caution. These
modules have a thin profile and are susceptible to damage when not handled carefully.
a. Disconnect the webcamera/microphone module cable (1) from the webcamera/
microphone module.
Display assembly 107
