3.
Remove the ExpressCard assembly (3) by sliding it up and to the right.
NOTE: Steps 4 and 5 apply only to computer models equipped with a 14.0-in display
assembly.
4. Lift the right side (1) of the ExpressCard assembly to disconnect it from the system board.
5. Remove the ExpressCard assembly (2) by sliding it up and to the right.
Reverse this procedure to install the ExpressCard assembly.
134 Chapter 4 Removal and replacement procedures
