18. Lift the antennas (2) and cables (3) straight up out of the display enclosure.
CAUTION: When installing the display assembly, be sure that the wireless antenna cables are
routed and arranged properly.
Failure to properly route the antennas can result in degradation of the computer's WLAN
performance.
19. If you need to remove the WWAN antennas, remove the antenna cables from the clips (1) and
routing paths built into the display enclosure.
20. Lift the antennas (2) and cables (3) straight up out of the display enclosure.
CAUTION: When installing the display assembly, be sure that the wireless antenna cables are
routed and arranged properly.
Failure to properly route the antennas can result in degradation of the computer's WWAN
performance.
21. If you need to remove the display latch, from the inside of the top of the display, squeeze
together the tabs that secure the latch to the display (1), and then remove the latch from the
display (2).
Component replacement procedures 115
