Item Component Spare part number
(13) Battery (Li ion):
9-cell, 100-Wh, 3.00-Ah 631243-001
9-cell, 100-Wh, 3.00-Ah 634087-001
9-cell, 73-Wh, 2.20-Ah 634089-001
6-cell, 62-Wh, 2.80-Ah 628668-001
6-cell, 55-Wh, 2.80-Ah 628670-001
6-cell, 51-Wh, 2.55-Ah 659083-001
3-cell, 31-Wh, 2.80-Ah 628664-001
(14) Bluetooth module 4.0 EDR
NOTE: The Bluetooth module cable is included in the Cable Kit, spare part number
641830-001.
655792-001
(15) Memory modules (PC3-12800, 1666-MHz, DDR3):
8-GB 670034-001
4-GB locked 707248-001
4-GB 641369-001
2-GB 652972-001
(16) WLAN module:
Atheros WB225 1×1 802.11b/g/n Bluetooth Combo Adapter 675794-001
Broadcom 43228 802.11abgn 2×2 Wi-Fi Adapter 669832-001
Intel Centrino Advanced-N 6205 WLAN module 695915-001
Intel Centrino Ultimate-N 6300 WLAN module 572511-001
Intel Centrino Wireless-N 2200 802.11b/g/n 2×2 WiFi Adaptor 670288-001
(17) WWAN module:
HP hs2350 HSPA+ Mobile Broadband Module 710788-001
HP lt2523 LTE/HSPA+ Mobile Broadband Module 710790-001
HP lt2522 LTE/EV-DO Mobile Broadband Module 710789-001
HP un2430 EV-DO/HSPA Mini Card 702080-001
HP un2430 EV-DO/HSPA Mobile Broadband Module 668969-001
(18) RTC battery 651948-001
(19) Optical drive (includes optical drive bezel and optical drive bracket):
Blu-ray ROM DVD±RW SuperMulti DL Drive 684330-001
DVD±RW Double-Layer with SuperMulti Drive 684329-001
DVD-ROM Drive 684328-001
38 Chapter 3 Illustrated parts catalog
