Page #151 background imageLoading...
Page #151 background image
CAUTION: Using Startup Repair completely erases hard drive contents and reformats the hard drive.
All files you have created and any software installed on the computer are permanently removed. When
reformatting is complete, the recovery process restores the operating system, as well as the drivers,
software, and utilities from the backup used for recovery.
1. If possible, back up all personal files.
2. If possible, check for the presence of the Windows partition and the HP Recovery partition. To find
the partitions, select Start > Computer.
NOTE: If the Windows partition and the HP Recovery partition have been deleted, you must
recover your operating system and programs using the Windows Vista operating system DVD and
the Driver Recovery disc (both purchased separately). For additional information, refer to
Using a
Windows Vista operating system DVD (purchased separately) on page 144.
3. Restart the computer, and then press f8 before the Windows operating system loads.
4. Select Repair your computer.
5. Follow the on-screen instructions.
NOTE: For additional information on recovering information using the Windows tools, perform a
search for these topics in Help and Support.
Using f11 recovery tools
CAUTION: Using f11 completely erases hard drive contents and reformats the hard drive. All files
you have created and any software installed on the computer are permanently removed. The f11
recovery tool reinstalls the operating system and HP programs and drivers that were installed at the
factory. Software not installed at the factory must be reinstalled. Personal files must be restored from a
backup.
NOTE: If your computer includes a solid-state drive (SSD), you may not have a recovery partition.
Recovery discs have been included for computers that do not have a partition. Use these discs to
recover your operating system and software. To check for the presence of a recovery partition, select
Start > Computer. If the partition is present, an HP Recovery drive is listed in the Hard Disk Drives
section of the window.
To recover the original hard drive image using f11, follow these steps:
1.
If possible, back up all personal files.
2. If possible, check for the presence of the HP Recovery partition. To find the partition, select Start
> Computer.
NOTE: If the HP Recovery partition has been deleted, you must recover your operating system
and programs using the Windows Vista operating system DVD and the Driver Recovery disc (both
purchased separately). For additional information, refer to
Using a Windows Vista operating
system DVD (purchased separately) on page 144.
3. Turn on or restart the computer, and then press esc while the “Press the ESC key for Startup Menu”
message is displayed at the bottom of the screen.
Windows Vista
143

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP ProBook 6560b and is the answer not in the manual?

HP ProBook 6560b Specifications

General IconGeneral
Bus typeDMI
SteppingJ1
Tjunction100 °C
Processor cache3 MB
Processor cores2
Processor modeli5-2410M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-2400 Mobile Series
Processor socketBGA 1023
Processor threads4
Processor codenameSandy Bridge
Processor frequency2.3 GHz
Processor cache typeSmart Cache
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency2.9 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)23
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® HM65 Express
HDD speed7200 RPM
HDD interfaceSATA
Optical drive typeDVD Super Multi DL
Card reader integratedYes
Total storage capacity320 GB
Compatible memory cardsMMC, SD
Number of HDDs installed1
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
TypePC
Modem speed56 Kbit/s
Intel segment taggingEnterprise
Compliance industry standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
Audio systemHD
Pointing deviceTouchpad
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version2.1+EDR
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Operating system installedWindows 7 Professional
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity0
AC adapter power65 W
Battery capacity55 Wh
Number of battery cells6
Product colorBlack
Country of originChina
On-board graphics card ID0x116
Discrete graphics card modelIntel® HD Graphics 3000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1200 MHz
Processor ARK ID52224
Processor package size37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth251 mm
Width374 mm
Weight2500 g
Height (front)34 mm
