Category Description
Modem 56K V.92 MDC data/fax modem
Modem cable not included
Supports “No Modem” option
Ethernet Realtek RTL8151EH-CG LAN 10/100/1000 network interface card (NIC)
S3/S4/S5 wake on LAN
NIC power down technology
Ethernet cable not included
Wireless Integrated WLAN options by way of wireless module:
Two WLAN antennas built into display assembly
Supports “no WLAN” option
Supports the following WLAN formats:
● Broadcom 802.11 b/g/n, 1×1
● Broadcom 802.11 a/b/g/n, 2×2
Integrated WWAN options by way of wireless module:
Two WWAN antennas built into display assembly (world-wide 5 band, in WWAN
panels only)
Subscriber identity module (SIM) security (customer-accessible in battery bay)
Supports “no WWAN” option
Supports the following WWAN modules:
● Gobi 3000: HP un2430 EV-DO/HSPA Mobile Broadband
●
Ericsson: HP hs2340 HSPA+ Mobile Broadband
Integrated personal area network (PAN) options by way of Bluetooth® module:
Supports “no PAN” option
Integrated Bluetooth 2.1
External media card One ExpressCard/54 slot
Integrated Media Card Reader with SD, MMC support
Ports Audio-in (stereo microphone)
Audio-out (stereo headphone)
DisplayPort 1.1a
RJ-11 (modem)
RJ-45 (Ethernet, includes link and activity lights)
USB 2.0 (4)
eSATA/USB 2.0 combo port
VGA (Dsub 15-pin) supporting 1920 × 1200 external resolution at 75-GHz (hot plug
with auto-detect)
3
