Item Description Spare part number
(1) Display assembly
NOTE: For a list of individual parts spared in the display panel, see
Display components
on page 25.
not spared
(2) Keyboard (includes cable)
NOTE: For a detailed list of available keyboards, see
Sequential part number listing on page 30.
For use in models without a pointing stick 641180-xxx
For use in models with a pointing stick 641179-xxx
(3) Top cover
●
For use on models that include a fingerprint reader, without a pointing stick 641204-001
●
For use on models that include a fingerprint reader and a pointing stick 641205-001
● For use on models that include a pointing stick, without a fingerprint reader 641206-001
(4) Fan 641183-001
(5) Heat sink (includes replacement thermal pads and grease) 658140-001
(6) System board (includes thermal pad)
For use in models with WWAN 658143-001
For use in models without WWAN 665718-001
(7) Speaker assembly 641186-001
(8) Processor (APU)
AMD Quad-Core A8-3510M (2.5-GHz/1.5-GHz, 4-MB L2 cache, 45W) 653358-001
AMD Quad-Core A6-3410M (2.3-GHz/1.6-GHz, 4-MB L2 cache, 45W) 653357-001
AMD Dual-Core A4-3310M (2.5-GHz/2.1-GHz, 2-MB L2 cache, 45W) 653356-001
AMD Dual Core E2-3000M (2.4-GHz/1.8-GHz, 1-MB L2 cache, 35W) 653351-001
(9) Modem module
NOTE: The modem module spare part kit does not include a modem module cable. The
modem module cable is included in the Cable Kit, spare part number 646968-001. See
Cable Kit on page 27 for more Cable Kit spare part number information.
628824-001
(10) Function board 658142-001
(11) USB board (includes Mylar) 658141-001
(12) Bottom cover (includes rubber feet)
NOTE: Make sure to remove the modem plug from the slot in the bottom cover if the
repaired unit includes a modem.
644695-001
(13) Battery, Li-ion
9-cell (100 WHr, 3.0 Ah) 631243-001
6-cell (62 WHr, 2.8 Ah) 628668-001
6-cell (55 WHr, 2.8 Ah, long life) 628670-001
3-cell (31 WHr, 2.8 Ah) 628664-001
22 Chapter 3 Illustrated parts catalog
