8. Remove the 2 Phillips PM2.0×6.0 screws from the top of the computer.
9. Pry up on the edges of the bottom cover to disengage the cover from the computer.
10. Remove the bottom cover from the computer.
Reverse this procedure to install the bottom cover.
NOTE: When replacing the bottom cover, make sure to remove the modem plug from the slot in the
bottom cover if the repaired unit includes a modem.
Component replacement procedures 77
