HP ProDisplay P201 Product End-Of-Life Disassembly Instructions

Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Description #1 Screw driver of "+" type
Description #2 Hexagonal nut screw driver for DVI and D-SUB connector
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Dismantle the screws of stand，get down the stand
2. Dismantle the screws of rear cover，
3. Dismantle the rear cover of monitor
4. Tear out all tapes.Remove the screws and disconnect the connectors to separate the MAINFRAME and PANELl
5. Remove the screws and disconnect the connectors.
6. Remove the MAIN BOARD and POWER BOARD
7.
8.
9.
10.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Pls. refer the attached:
EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01

HP ProDisplay P201 Specifications

General

3D	No
HD type	-
Pixel pitch	0.2768 x 0.2768 mm
Display surface	Matt
Display diagonal	20 \
Display resolution	1600 x 900 pixels
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1600 x 900
On/off switch	Yes
Ethernet LAN (RJ-45) ports	0
LED indicators	Power
Tilt angle range	-5 - 25 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Certification	TCO
Product color	Black
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, DVI, VGA
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	151.1 mm
Height (with stand)	359.2 mm
Depth (without stand)	47.5 mm
Width (without stand)	482 mm
Height (without stand)	294.1 mm
Weight (without stand)	3500 g
