4. Highlight the enclosure in the rack and click Config. The enclosure configuration page appears as
shown in Figure 15.
Figure 15. Initial c7000 enclosure configuration screen
NOTE
The enclosure must be configured with a power supply and
interconnect modules BEFORE adding and configuring the blades.
5. Click the Config button. The enclosure configuration screen appears. Configure the enclosure as to
power supply type and quantity, number of cooling fans, and interconnect modules as shown in
Figure 16. When finished, click Save.
Figure 16. c7000 enclosure configuration screen
17
