Intel Gen8 Supported Memory Bandwidth for HP ProLiant Gen8 Intel® Xeon®E5-2400 Series Processor Family
Memory Bandwidth and Capacity
DIMM Type
Registered DIMMS
(RDIMMs)
Load
Reduced
(LRDIMMs)
Unbuffered with ECC DIMMs (UDIMMs)
DIMM Rank
Single
Rank
Single
Rank
Dual
Rank
Dual
Rank
Single
Rank
Dual
Rank
Dual
Rank
Quad Rank
Single
Rank
Single
Rank
Dual
Rank
Dual
Rank
Dual
Rank
Dual
Rank
DIMM Capacity
4GB 4GB 8GB 8GB 8GB
16GB 16GB 32GB
2GB 2GB 4GB 4GB 8GB 8GB
DIMM Native
Speed (MT/s)
1333 1600 1333 1600 1600 1333 1600 1333 1333 1600 1333 1600 1600 1333
Voltage
LV
Std
LV
Std Std
LV
Std
LV LV
Std
LV
Std Std
LV
SLOTS THAT CAN BE POPULATED
12 slot servers
12 12 12 12 12 12 12 12 12 12 12 12 12 12
MAXIMUM CAPACITY (GB)
*
48 48 96 96 96 192 192 384 24 24 48 48 96 96
1 DIMM Per
Channel
1333 1600 1333 1600 1600 1333 1600 1333
***
1333 1600 1333 1600 1600 1333
2 DIMM Per
Channel
1333 1600 1333 1600 1600 1333 1600 1333
***
1333
***
1600 1333
***
1600 1600 1333
***
3 DIMM Per
Channel
1066 1333
***
1066
**
1333
**
1333
**
1066
**
1333
**
1600
n/a n/a n/a n/a n/a n/a
NOTE:
To realize the performance memory capabilities listed above HP SmartMemory is required.
*Maximum capacity will vary based on individual server platform qualification schedule
**LRDIMM enables 2 DIMMs per channel. HP SmartMemory supports up to 2DPC@1333 at 1.35V. Third party memory may only support
up to 2DPC@1066 at 1.5V.
*** For UDIMMs, HP SmartMemory supports 2DPC@1333 at 1.35V. Third party memory may only support up to 2DPC@1066 at 1.5V.
DIMM slot and configuration diagrams
Basic memory slot & population diagram
Population order; looking from the front of your server CPU#1 is on right side and CPU#2 is on the left. See the population order
by alphabetic and numeric progression below.
CPU #1 IS PROCESSOR ON RIGHT - LOOKING FROM FRONT OF SERVER
CPU 1 CPU 2
Slot #
population order
Slot #
population order
CPU 1
Chnl 1
1
A
1 1
A
1
2
D
4 2
D
4
CPU 1 CPU 2
Slot #
population order
Slot #
population order
CPU 2
Chnl 2
3
B
2 3
B
2
4
E
5 4
E
5
QuickSpecs
HP ProLiant DL360e Generation 8 (Gen8)
Memory
DA - 14327 North America — Version 36 — January 22, 2014
Page 55
