NOTE:
NOTE:NOTE:
NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO
product offerings and requirements.
NOTE:
NOTE:NOTE:
NOTE:
HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must start
with a CTO Chassis.
NOTE:
NOTE:NOTE:
NOTE:
FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
Step 1: Base Configuration (choose one of the following configurable models)Step 1: Base Configuration (choose one of the following configurable models)
Step 1: Base Configuration (choose one of the following configurable models)
Models
ModelsModels
Models
HP ProLiant DL380G5 Rack CTO Chassis
391835-B21
Factory Integrated Model ships with:
Factory Integrated Model ships with:Factory Integrated Model ships with:
Factory Integrated Model ships with:
(8) SFF Serial Attached SCSI (SAS) Drive Bays
Two embedded NC373i Multifunction Gigabit Server Adapters
PCI-Express Riser Cage
800Watt hot plug power supply, CE Mark Compliant
One IEC Power cord
Rack (2U), (3.5-inch)
Step 1A: Choose Controller (must choose only one of the following)
Step 1A: Choose Controller (must choose only one of the following)Step 1A: Choose Controller (must choose only one of the following)
Step 1A: Choose Controller (must choose only one of the following)
Controllers
ControllersControllers
Controllers
HP Smart Array P400/256 for DL380 G5/ DL385 G2 FIO Controller
NOTE:
NOTE: NOTE:
NOTE:
PCI Express
405160-B21
HP Smart Array P400/512 BBWC for DL380 G5/ DL385 G2 FIO Controller
NOTE:
NOTE: NOTE:
NOTE:
PCI Express
405162-B21
HP Smart Array E200/128 BBWC Controller
NOTE:
NOTE: NOTE:
NOTE:
PCI Express
411508-B21
HP Smart Array P800/512 BBWC Controller
NOTE:
NOTE: NOTE:
NOTE:
PCI Express SA-P800 Controller supports both internal and external drives.
381513-B21
HP Smart Array P600/256 BBWC Controller
NOTE:
NOTE: NOTE:
NOTE:
PCI-X. SA-P600 Controller supports both internal and external drives.
337972-B21
HP Smart Array P600 w/512 FIO Ctrlr
432103-B21
HP Smart Array E200/64 FIO Controller
405528-B21
Step 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwiseStep 2: Choose Required Options (only one of the following from each list unless otherwise
Step 2: Choose Required Options (only one of the following from each list unless otherwise
noted)
noted)noted)
noted)
Processors
ProcessorsProcessors
Processors
Quad-Core Processors
Quad-Core ProcessorsQuad-Core Processors
Quad-Core Processors
Quad-Core Intel® Xeon® Processor X5470 (3.33 GHz, 120 Watts, 1333 FSB)
DL380 FIO Kit
484309-L21
Quad-Core Intel® Xeon® Processor X5460 (3.16 GHz, 120 Watts, 1333 FSB)
DL380 FIO Kit
458581-L21
Quad-Core Intel® Xeon® Processor X5450 (3.0 GHz, 120 Watts, 1333 FSB) DL380
FIO Kit
462593-L21
Quad-Core Intel® Xeon® Processor E5450 (3.0 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458583-L21
Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB) DL380
FIO Kit
458585-L21
QuickSpecs
HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)HP ProLiant DL380 Generation 5 (G5)
HP ProLiant DL380 Generation 5 (G5)
Configuration Information - Factory Integrated Models
DA - 12477 North America — Version 63 — September 23, 2010
Page 15
