HP ProLiant DL380 Generation 5

Illustrated parts catalog 21
Item Description Assembly part
number
Spare part
number
Customer self
repair (on
page 6)
10 I/O fan bracket — — —
a) I/O fan bracket, 12-fan model 419315-001 408784-001 Mandatory
1
b) I/O fan bracket, 6-fan model* 441015-001 442954-001 Optional
2
11 Power supply — — —
a) AC hot-plug power supply, 1000-W 380622-001 403781-001 Mandatory
1
b) DC hot-plug power supply, 1200-W 412837-001 419613-001 Mandatory
1
12 PCI riser cage — — —
a) PCI riser cage, with non-hot-plug PCIe
(standard)
412878-001 408786-001 Optional
2
b) PCI riser cage, with non-hot-plug PCI-
X/PCIe (optional)*
412878-002 408788-001 Optional
2
13 Air baffle — — —
a) Air baffle, 12-fan model 394039-002 408782-001 Mandatory
1
b) Air baffle, 6-fan model* 440932-001 442952-001 Mandatory
1
14 Processor — — —
a) 3.00-GHz Intel® Xeon® processor 5050,
dual-core, 4-MB cache, 667-MHz FSB* **
405176-004 409423-001 Optional
2
b) 3.20-GHz Intel® Xeon® processor 5060,
dual-core, 4-MB cache, 1066-MHz FSB* **
398571-002 409424-001 Optional
2
c) 3.73-GHz Intel® Xeon® processor 5080,
dual-core, 4-MB cache, 1066-MHz FSB* **
398571-001 412955-001 Optional
2
d) 1.60-GHz Intel® Xeon® processor 5110,
dual-core, 2×2-MB L2 cache, 1066-MHz
FSB* **
409408-002 416795-001 Optional
2
e) 1.86-GHz Intel® Xeon® processor 5120,
dual-core, 2×2-MB L2 cache, 1066-MHz
FSB* **
409408-001 416794-001 Optional
2
f) 2.0-GHz Intel® Xeon® processor 5130,
dual-core, 2×2-MB L2 cache, 1333-MHz
FSB* **
416162-001 416796-001 Optional
2
g) 2.33-GHz Intel® Xeon® processor 5140,
dual-core, 2×2-MB L2 cache, 1333-MHz
FSB* **
416162-002 416797-001 Optional
2
h) 2.33-GHz Intel® Xeon® processor 5148,
dual core, 2x2-MB L2 cache, 1333-MHz
FSB, low-voltage* **
416169-001 431716-001 Optional
2
i) 2.66-GHz Intel® Xeon® processor 5150,
dual-core, 2×2-MB L2 cache, 1333-MHz
FSB* **
416162-003 416798-001 Optional
2
j) 3.0-GHz Intel® Xeon® processor 5160,
dual-core, 2×2-MB L2 cache, 1333-MHz
FSB* **
416162-004 416799-001 Optional
2
