Removal and replacement procedures 46
4.
Remove the PPM.
IMPORTANT: PPM slots must be populated when processors are installed. If PPM slots are not
populated, the server halts during POST or does not boot.
To replace the component, reverse the removal procedure.
PPM retainer
To remove the component:
1. Power down the server (on page 30).
2. Extend the server from the rack (on page 29).
3. Remove the access panel ("Access panel" on page 32).
4. Remove the PPMs ("PPM" on page 45).
