Removal and replacement procedures 53
8.
Close and lock the heatsink retaining latches.
9. Install the access panel ("Access panel" on page 32).
10. Install the server into the rack.
11. Power up the server.
Battery-backed write cache procedures
Two types of procedures are provided for the BBWC option:
• Removal and replacement of failed components:
o Removing the cache module (on page 53)
o Removing the battery pack (on page 54)
• Recovery of cached data from a failed server ("Recovering data from the battery-backed write
cache" on page 55)
CAUTION: Do not detach the cable that connects the battery pack to the cache module.
Detaching the cable causes any unsaved data in the cache module to be lost.
Removing the cache module
To remove the component:
1. Power down the server (on page 30).
2. Extend or remove the server from the rack ("Remove the server from the rack" on page 31).
3. Remove the access panel ("Access panel" on page 32).
4. Remove the controller ("Expansion board (slots 1 and 2)" on page 65).
