Hot-plug fans (12-fan configuration)
For server models that support 12 fans, the fan configuration operates in redundant mode when all 12
fans are installed.
Fan board components
Item Description
1 Fan connectors (8)*
2 Systems Insight Display connector
3 Power On/Standby button/system power LED
4 UID LED button
5 USB connectors (2)
6 Video connector
7 Fan board system connector
