HP ProLiant DL380 Generation 6 User Manual

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of
HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years
from date of purchase. Support for software and initial setup is available for 90 days from date of purchase.
Enhancements to warranty services are available through HP Care Pack services or customized service
agreements. SATA hard drives have a one-year warranty. SAS Enterprise drives have a three-year warranty.
NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day
response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These
parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor
charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also
designed for easy replacement but may involve added complexity. Customers may choose to have HP replace
Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical
support is available at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
QuickSpecs
HP ProLiant DL380 Generation 6
Overview
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009 Page 3

HP ProLiant DL380 Generation 6 Specifications

General

Chipset	Intel 5520 Chipset
Form Factor	2U Rack
Processor	Intel Xeon 5500 and 5600 Series
Memory	Up to 192 GB DDR3 Registered or Unbuffered DIMMs
Storage	Up to 16 SFF SAS/SATA drives
RAID	HP Smart Array P410
Network	Embedded NC382i Dual Port Multifunction Gigabit Server Adapter
Power Supply	460W, 750W, or 1200W
Expansion Slots	6 PCI-Express Gen2 slots
Management	HP Integrated Lights-Out 2 (iLO 2)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
