HP ProLiant DL380 Generation 6 User Manual

(Optional Secondary) Slots # Width ** Width Number *
4 PCIe Gen2 X8 X16 16 Full length,
full height
slot
5 PCIe Gen2 X4 X8 20 Half length,
half height
slot
6 PCIe Gen2 X4 X8 23 Half length,
half height
slot
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
PCIe/PCI-X Riser
(Optional Primary)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
1 PCI-X
(133MHz)
64-bit N/A 7 Full length,
Full Height
2 PCI-E Gen2 X8 X16 11 Half Length,
Full Height
3 PCI-E Gen2 X4 X8 15 Half Length,
Full Height
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
PCIe/PCI-X Riser
(Optional Secondary)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
4 PCI-X
(133MHz)
64-bit Not
applicable
19 Full length,
Full height
slot
5 PCI-E Gen2 X8 X16 23 Half Length,
Half Height
6 PCI-E Gen2 X4 X8 27 Half Length,
Half Height
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
x16 PCIe Riser
(Optional Primary)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
1 PCIe Gen2 x16 x16 13 Full Length,
Full Height
slot
Supports up
to 225W;
single wide
cards only
* Default bus assignment (in decimal). Inserting cards with PCI bridges may alter the actual bus
assignment number
** Indicates the number of physical electrical lanes running to the connector.
x16 PCIe Riser
(Optional Secondary)
Expansion
Slots #
Technology Bus
Width **
Connector
Width
Bus
Number *
Form Factor Notes
QuickSpecs
HP ProLiant DL380 Generation 6
Standard Features
DA - 13234 Worldwide QuickSpecs — Version 16 — 8.28.2009 Page 6

HP ProLiant DL380 Generation 6 Specifications

General

Chipset	Intel 5520 Chipset
Form Factor	2U Rack
Processor	Intel Xeon 5500 and 5600 Series
Memory	Up to 192 GB DDR3 Registered or Unbuffered DIMMs
Storage	Up to 16 SFF SAS/SATA drives
RAID	HP Smart Array P410
Network	Embedded NC382i Dual Port Multifunction Gigabit Server Adapter
Power Supply	460W, 750W, or 1200W
Expansion Slots	6 PCI-Express Gen2 slots
Management	HP Integrated Lights-Out 2 (iLO 2)
Operating System Support	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
