Opening the Server
The access panel and the front bezel
are both detachable. You need
to remove these system
covers before you can remove or replace a
server component.
Removing the Access Panel
Removing the Front Bezel
Installing Mass Storage Devices
The lower drive bay on the fr
ont panel accommodates an HDD
cage for installation of up to four additional hard drives. The
hot-plug HDD cage model supports SATA drives only, while the
non-hot-plug model supports both SATA and SCSI drives.
CAUTION: Drives can be damaged by static electricity. Before
handling drives, touch an unpainted metal surface to discharge
static electricity.
WARNING: If you are going to install a non-hot-plug drive,
power down the server first.
Non-hot-plug SCSI Drives
Non-hot-plug SATA Drives
