Removal and Replacement Procedures
This chapter provides subassembly/module-level removal and replacement procedures for the
HP ProLiant ML110 Generation 2 server.
Review the specifications of a new component before installing it to make sure it is
compatible with the server. When you integrate new components into the system, record its
model and serial number, and any other pertinent information for future reference. After
completing any removal or replacement procedure, run the diagnostics program to verify that
all components operate properly.
Hardware Configuration Tools
In performing any hardware configuration procedure you may need the following tools:
• T-15 Torx screwdriver
• Flat-blade screwdriver
NOTE: The figures used in this chapter to illustrate procedural steps are labeled numerically (i.e., 1,
2…). When these figures are used in substep items, the alphabetically labeled instructions correspond
to the numbered labels on the related figure (i.e., Label 1 corresponds to step a, label 2 corresponds to
step b, etc.).
Hardware Configuration Information
WARNING: Only authorized technicians trained by HP should attempt to repair this
equipment. Because of the complexity of the individual boards and subassemblies, no
one should attempt to make repairs at the component level or to make modifications to
any printed wiring board. Improper repairs can create a safety hazard.
CAUTION: Electrostatic discharge (ESD) can damage electronic components. Be sure that
you are properly grounded (earthed) before beginning any installation procedure. Refer to the
“Electrostatic Discharge Information” section for more information.
Before removing any serviceable parts, determine whether the part is hot-plug or
non-hot-plug.
HP ProLiant ML110 Generation 2 Server Maintenance and Service Guide 2-1
