Illustrated parts catalog 21
Item Description Spare part number
Customer self
repair
1 SATA cable 452334-001 Mandatory
1
2 SAS LED cable 444692-001 Mandatory
1
3 SAS HDD cable 457892-001 Mandatory
1
Mass storage devices
4 Removable media drive Mandatory
1
a) SATA DVD-ROM drive 460697-001
b) SATA DVD-RW drive 460698-001
5 160-GB non-hot-plug SATA hard drive
399968-001
Mandatory
1
6 72-GB non-hot-plug SAS hard drive
432151-001
Mandatory
1
7 Heat sink fan 457886-001 Optional
2
8 Processor (include alcohol pad and thermal
compound)
Optional
2
Intel Pentium Dual-Core Processor
a) E2160 (1.80 GHz, 800 MHz FSB, 1 MB L2) 455623-001
b) E5200 (2.5 GHz, 800 MHz FSB, 2MB L2) 503382-001
c) E7400 (2.8 GHz, 1066 MHZ FSB, 3 MB L2 ) 508255-001
Dual-Core Intel Xeon Processor
a) 3065 (2.33 GHz, 1333 MHz FSB, 4 MB L2) 454525-001
b) 3075 (2.66 GHz, 1333 MHz FSB, 4 MB L2) 454526-001
c) 3085 (3.0 GHz, 1333 MHz FSB, 4 MB L2) 454527-001
d) E3110 (3.0 GHz, 1333 MHz FSB, 6MB L2) 463509-001
e) E3120 (3.16 GHz, 1333 MHz FSB, 4 MB L2) 493930-001
Quad-Core Intel Xeon Processor
a) X3210 (2.13 GHz, 1066 MHz FSB, 8 MB L2) 457020-001
b) X3220 (2.4 GHz, 1066 MHz FSB, 8 MB L2) 454529-001
c) X3320 (2.5 GHz, 1333 MHz FSB, 6 MB L2) 463508-001
d) X3350 (2.66 GHz, 1333 MHz FSB, 12 MB L2) 463507-001
e) X3330 (2.66 GHz, 1333 MHz FSB, 8 MB L2) 493929-001
f) X3360 (2.4 GHz, 1066 MHz FSB, 8 MB L2) 469858-001
g) X3370 (3.0 GHz, 1333MHz FSB, 12MB L2) 493928-001
Intel Core 2 Duo Processor
E4400 (2.0 GHz, 800 MHz FSB, 2 MB L2) 454528-001
Intel Celeron Processor 400 Sequence
