Connectors, switches, and LEDs 75
Connectors, switches, and LEDs
Connectors and components
Front panel
Item Icon Component
1 Optical disc drive (ODD)
2 ODD manual eject hole
3 ODD eject button
4
Power button
5
Front USB 2.0 ports
6 HDD EMI shield
7 HDD EMI shield screw
8 2
nd
removable media drive bay EMI shield
NOTE: The location of items 2 and 3 may vary depending on the model of the installed removable media drive.
