10 Reference and Troubleshooting Guide
Item Description
2 Optional hot-plug redundant power supply bay
3 SCSI connector knockouts
4 PCI Express 4x (half length card), slot 1
5 PCI Express 8x (full length card), slot 2
6 64-bit 100 MHz PCI-X slot, bus 9, slot 3
7 64-bit 100 MHz PCI-X slot, bus 9, slot 4
8 64-bit 133 MHz PCI-X slot, bus 6, slot 5
9 64-bit 66 MHz PCI-X slot, bus 2, slot 6
10 RJ-45 Ethernet connector
11 USB 2.0 connectors (2)
12 Video connector
13 Parallel connector
14 Serial connector
15 Keyboard connector
16 Mouse connector
