Component identification 77
Item Description Status
15
Memory mode Green = System is in online spare memory mode
Off = Normal operation
System LEDs and internal health LED combinations
When the internal health LED on the front panel illuminates either amber or red, the server is experiencing a
health event. Combinations of illuminated system LEDs and the internal health LED indicate system status.
The front panel health LEDs indicate only the current hardware status. In some situations, HP SIM may report
server status differently than the health LEDs because the software tracks more system attributes.
System LED and color
Internal health LED
color
Status
Processor failure,
socket X (amber)
Red One or more of the following conditions may exist:
Processor in socket X has failed.
Processor in socket X failed over to the second processor.
Processor X is not installed in the socket.
Processor X is not supported.
Processor heatsink is not attached properly.
Amber Processor in socket X is in a pre-failure condition.
Processor failure, both
sockets (amber)
Red Processor types are mismatched.
PPM failure (amber)
Red
PPM has failed.
PPM is not installed, but the corresponding processor is
installed.
FBDIMM failure, slot X
(amber)
Red
FBDIMM in slot X has failed.
FBDIMM in slot X is an unsupported type, and no valid
memory exists in another bank.
Amber
FBDIMM in slot X has reached single-bit correctable error
threshold.
FBDIMM in slot X is in a pre-failure condition.
FBDIMM in slot X is an unsupported type, but valid
memory exists in another bank.
Overtemperature
(amber)
Red
The Health Driver has detected a cautionary temperature
level.
The server has detected a hardware critical temperature
level.
Fan (amber)
Red The minimum fan requirements are not being met. Fan has
failed.
Amber A fan has failed but still meets the minimum fan requirements
(with redundant fan option only).
