NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
DDR3 memory population guidelines
For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
www.hp.com/go/ddr3memory-configurator
General Guidelines:
White DIMM slots denote the first slot of a channel. For 1 DPC (DIMM per channel) populate white slots only.
Install DIMMs only if the corresponding processor is installed.
If only one processor is installed in a two processor system, only half of the DIMM slots are available.
To maximize performance, balance the total memory capacity between all installed processors
Populate DIMMs from heaviest load (quad-rank) to lightest load (single-rank) within a channel
Heaviest load (DIMM with most ranks) within a channel goes furthest from the processor
Do not mix UDIMMs, RDIMMs or LRDIMMs
Quad rank LR DIMMs are supported at 3 DIMMs per channel.
DIMMs of different voltages (1.35V & 1.5V) may be mixed in any order
The system will power them at the higher voltage
DIMMs of different speed grades may be mixed in any order
The system will select a common optimal speed
Memory speed is a function of the processor QPI bus speed.
Population Guidelines:
There are four (4) channels per processor; eight (8) channels per server
There are three (3) DIMM slots for each memory channel; twenty-four (24) total slots
Memory channels1 and 3 consists of the three (3) DIMMs that are furthest from the processor
Memory channel 2 and 4 consists of the three (3) DIMMs that are closest to the processor
ML350p Gen8-IVB Supported Memory Bandwidth and Capacity -- Treaty
DIMM
Type
Registered DIMMS (RDIMMs)
Load
Reduced
(LRDIMMs)
Unbuffered with ECC DIMMs (UDIMMs)
DIMM
Rank
Single Rank (1R)
Dual Rank (2R)
Quad Rank
(4R)
Single Rank
(1R)
Dual Rank (2R)
DIMM
Capacity
4GB 4GB 8GB 8GB 8GB 8GB
16GB 16GB 32GB
2GB 2GB 4GB 4GB 8GB 8GB
DIMM
Native
Speed
(MHz)
1600 1866 1600 1866 1600 1866 1600 1866 1866 1600 1866 1600 1866 1600 1866
Voltage
LV
Std
LV
Std
LV
Std
LV
Std Std
LV
Std
LV
Std
LV
Std
SLOTS THAT CAN BE POPULATED
24 slot
servers
24 24 24 24 24 24 24 24 24 16 16 16 16 16 16
MAXIMUM CAPACITY (GB)
*
24 slot
servers
96 96 192 192 192 192 384 384 768 32 32 64 64 128 128
QuickSpecs
HP ProLiant ML350p Generation 8 (Gen8)
Memory
DA - 14226 North America — Version 41 — December 9, 2013
