2 DIMM
Per
Channel
1333 1600 1600 1333 1600 1333 1600 1333
**
1333
***
1600 1333
***
1600 1333
***
1600
3 DIMM
Per
Channel
800 1066 1066 800 1066 800 1066 1066
n/a n/a n/a n/a n/a n/a
NOTES:
Memory speed is a function of the processor QPI bus speed.
To realize the performance memory capabilities listed above HP SmartMemory is required.
* Maximum capacity will vary based on individual server platform qualification schedule
** LRDIMM enables 3 DIMMs per channel. HP SmartMemory will supports up to 3DPC@DDR3-1066 at 1.35V. Third party memory may
only support 3DPC @DDR3-1066 at 1.5V.
*** For HP SmartMemory, UDIMM is, supported at 2DPC@1333. Third party memory may only support up to 2DPC@1066.
Memory Speed by Processor Model
Processor Models
Supported Memory Speeds
E5-2680, E5-2670, E5-2667, E5-2665, E5-2660, E5-2650, E5-2650L, E5-2637
1600/1333/1066MHz
E5-2640, E5-2630, E5-2630L, E5-2620
1333/1066MHz
E5-2609, E5-2603
1066MHz
E5-2697 v2, E5-2690 v2, E5-2670 v2, E5-2667 v2, E5-2650 v2, E5-2643 v2, E5-2637
v2
1866/1600/1333/1066MHz
E5-2640 v2, E5-2630 v2, E5-2630L v2, E5-2620 v2
1600/1333/1066MHz
E5-2609 v2, E5-2603 v2
1333/1066MHz
Standard and Maximum Memory Capacity (Pre-configured Models)
Pre Configured Models
Standard Memory
Maximum Memory Plus
Optional Memory
Standard Memory Replaced with Optional
Memory
Intel Xeon E5-2640
16GB (4x 4GB)
336GB (20x16GB, 4x4GB)
768GB (24 x 32GB)
Intel Xeon E5-2620
8GB (2x 4GB)
360GB (22x16GB, 2x4GB)
768GB (24 x 32GB)
Intel Xeon E5-2603
4GB (1x 4GB)
372GB (23x16GB, 1x4GB)
768GB (24 x 32GB)
Intel Xeon E5-2640 v2
16GB (2x 8GB)
336GB (20x16GB, 4x4GB)
768GB (24 x 32GB)
Intel Xeon E5-2620 v2
8GB (1x 8GB)
360GB (22x16GB, 2x4GB)
768GB (24 x 32GB)
Intel Xeon E5-2609 v2
4GB (1x 4GB)
372GB (23x16GB, 1x4GB)
768GB (24 x 32GB)
DIMM slot and configuration diagrams
Basic memory slot & population diagram
Population order; start with "A" first, "B" second, "C" third, etc.
QuickSpecs
HP ProLiant ML350p Generation 8 (Gen8)
Memory
DA - 14226 North America — Version 41 — December 9, 2013
Page 55
