Cabling overview
This section provides guidelines that help you make informed decisions about cabling the server and
hardware options to optimize performance.
For information on cabling peripheral components, refer to the white paper on high-density deployment at
the HP website (http://www.hp.com/products/servers/platforms).
CAUTION: When routing cables, always be sure that the cables are not in a position where they
can be pinched or crimped.
Diskette drive cabling
SAS cabling
NOTE: The center wall is removed for illustration purposes only.
• SAS data cabling
IMPORTANT: When installing a x3/x1 SAS cable, HP recommends that the x3 part of the x3/x1
cable be linked to the SAS drive backplane connector that corresponds to drive slots 1 to 4. In this
setup, drive slot 1 will not be available, but since drive slots 2 to 4 will be connected, one
continuous volume can be created.
