9-14
Configuring and Monitoring Port Security
Port Security Command Options and Operation
mined by the current address-limit value). For example, suppose port A1
allows two authorized devices, but has only one device in its Authorized
Address list:
Figure 9-4. Example of Adding an Authorized Device to a Port
With the above configuration for port A1, the following command adds the
0c0090-456456 MAC address as the second authorized address.
ProCurve(config)# port-security a1 mac-address 0c0090-
456456
After executing the above command, the security configuration for port A1
appears as:
Figure 9-5. Example of Adding a Second Authorized Device to a Port
