HP PS/2 Optical Scroll
Mouse
Dimensions
(H x L x W)
3.95 x 6.21 x 11.7 cm (1.56 x 2.44 x 4.61 in)
Weight
4.44 oz (126 g)
Environmental
Operating temperature
-32° to 104°F (0° to 40° C)
Non-operating
temperature
-4° to 140°F ( -20° to 60° C)
Operating humidity
10% to 90% (non condensing at ambient)
Non-operating humidity
10% to 90% non condensing
Operating shock
40 g, 6 surfaces
Non-operating shock
80 g, 6 surfaces
Operating vibration
2 g peak acceleration
Non-operating
vibration
4 g peak acceleration
Drop
(out of box)
80 cm height onto asphalt tile over concrete
or equivalent, 5-drop in 5 direction except the
cable face
Electrical
Operating voltage
5 VDC ± 10%
Power consumption
100mA
System consumption
PS/2 mini-din connector
ESD
CE level 4, 15 kV air discharge
EMI-RFI
Conforms to FCC rules for a Class B
computing device
Microsoft PC99 - 2001
Functionally compliant
Mechanical
Resolution
400 ± 20% DPI
Tracking speed
10 in/s (25.4 cm/s) maximum
Acceleration
100 in/s/s (2.54 m/s/s)
Switch actuation
61 g nominal peak force
Switch life
3,000,000 operations (using Hasco modified
tester)
Switch type
Low force micro-switches
Tracking mechanism
life
155 mi (250 km) at average speed of 10 in/s
Cable length
6 ft (1.8 m)
Microsoft PC99 - 2001
Mechanically compliant
Scroll wheel
Width
8 mm
Diameter
1.01 in (25.6 mm)
Maximum rotation
speed
48 rats/sec
Switch type
Light force micro-switch
Switch life
1 million operations
Mechanical life
Minimum 200,000 revolutions
Regulatory approvals
Compliant
UL, CSA, FCC, CE Mark, TUV, TUV GS,
VCCI, BSMI, C-Tick, MIC
HP USB Optical Scroll
Mouse
Dimensions
(H x L x W)
1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm)
Weight
0.27 lb (0.12 kg)
Cable length
72.8 in (185 cm)
System requirements
Microsoft Windows 95, 98, 2000, Me, XP and Vista
Available USB port
QuickSpecs
HP Compaq dc7900 Business PC
Technical Specifications - Input/Output Devices
DA - 13029 Worldwide QuickSpecs — Version 24 — 10/30/2009
Page 50
