HP QUICKSPECS DC7900 User Manual

SATA DVD-ROM Slim
Drive
Height 12.7mm
Orientation Either horizontal or vertical
Interface type SATA/ATAPI
Dimensions (W x H x D) 5.0 x 0.5 x 5.0 in (128 x 13.6 x 129 mm)
Weight (max) 0.42 lb (190 g)
Read speeds DVD+R/-R/+RW/
-RW/+R DL /-R DL
Up to 4X
DVD-ROM Up to 8X
CD-ROM, CD-R Up to 24X
CD-RW Up to 24X
Access time
(typical reads, including
settling)
Random DVD DVD: < 140 ms (typical), CD: < 125 ms
(typical)
Random CD DVD: < 250 ms (seek), CD: < 210 ms (seek)
Data Transfer Modes ATA PIO mode 4 (16.7 MB/s); ATA Multi-word
DMA mode 2 (16.7 MB/s)
Power Source Four-pin, DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC - <1000 mA typical, < 1600 mA
maximum
Total Drive Power
(standby mode)
< 2.5 Watt
Audio output Line-Out 0.7 VRMS
Signal-to-Noise Ratio 74 dB
Channel Separation 65 dB
Environmental (all
conditions non-
condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 5% to 85%
Maximum Wet Bulb
Temperature (operating)
86° F (30° C)
QuickSpecs
HP Compaq dc7900 Business PC
Technical Specifications - Optical Storage
DA - 13029 Worldwide QuickSpecs — Version 24 — 10/30/2009 Page 55

HP QUICKSPECS DC7900 Specifications

General

Chipset	Intel Q45 Express
Memory	Up to 16 GB DDR2 SDRAM
Memory Slots	4 DIMM slots
Audio	Integrated High Definition Audio
Dimensions	Varies by form factor
Weight	Varies by form factor
Processor	Intel Core 2 Duo, Intel Core 2 Quad, Intel Pentium Dual-Core
Storage	Up to 1TB SATA HDD
Graphics	Integrated Intel GMA 4500, optional discrete graphics
Optical Drive	DVD-ROM, DVD+/-RW, or Blu-ray
Network	Integrated Gigabit Ethernet
Ports	USB 2.0, serial, parallel
Expansion Slots	PCI, PCIe x1, PCIe x16
Operating System	Windows Vista, Windows XP, FreeDOS
Form Factor	Ultra-slim desktop, small form factor, or convertible minitower
