HP QuickSpecs HP Z8 G4 - Page 54

QuickSpecs
HP Z8 G4 Workstation
Technical Specifications - Graphics
c05527763 — DA - 15956 Worldwide — Version 3 — November 1, 2017
Page 54
5120 x 2880 x 24 bpp @ 60Hz
Image Quality Features
12-bit internal display pipeline (hardware support for 12-bit scanout on
supported panels, applications and connection)
Stereoscopic 3D display support including NVIDIA® 3D Vision™ technology,
NVIDIA® Mosaic and nView.
Display Output
Maximum number of displays
- 4 direct attached monitors
Maximum number of monitors across all available NVIDIA® Quadro® P2000
outputs is 4.
Shading Architecture
Shader Model 5.1
Supported Graphics APIs
OpenGL
®
4.5
DirectX
®
12
API support includes:
CUDA C, CUDA C++, DirectCompute 5.0, OpenCL™, Java, Python, and Fortran
software
Available Graphics
Drivers
Microsoft Windows 10
Microsoft Windows 7 Professional 64bit
Linux® - Full OpenGL® implementation, complete with NVIDIA® Quadro®
and ARB extensions
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
Notes
Radeon™ Pro WX 3100
4GB Graphics
Form Factor
Low-Profile Single Slot (6.6” Length )
Graphics Controller
Polaris12 GL
GPU: 512 Stream Processors organized into 8 Compute Units
Power: 50 Watts
Cooling: Active
Memory
4GB GDDR5 memory
Memory Bandwidth: 6 Gbps / 96 GB/s
Memory Width: 128 bit
Connectors
2x Mini DisplayPort™ 1.4 plus 1x DisplayPort™ 1.4 – HDR ready connectors
with HBR3 and MST support.
Factory Configured: No adapters included
After market option kit: One mDP-to-DP cable adapters included
Additional Mini DisplayPort™-to-DisplayPort™, DisplayPort™-to-VGA or
DisplayPort™-to-DVI adapters are available as Factory Configuration or
Option Kit accessories.
Maximum Resolution
5K support @ 60Hz
 1x single-cable 5K monitor, or 2x dual-cable 5K monitors
3x 4K support @ 60Hz
