To enable long-page scans in an HP Smart Document Scan Software profile, follow these
steps:
1. Open the HP Smart Document Scan Software.
2. Select a scan profile, and then click Edit.
3. Set the page size:
On the Scan tab of the Profile Settings dialog box, select Custom in the Size
drop-down list, and then type the actual page dimensions, up to 216 mm x 864
mm (8.5 in x 34 in), in the Width and Height boxes.
TIP: Alternatively, you can select Maximum in the Size drop-down list. The
resulting scanned image size will be 216 mm (8.5 in) wide and the actual page
length up to 864 mm (34 in) long.
NOTE: In other scanning software, the page size settings are on the Layout tab
of the ISIS or TWAIN Advanced Settings dialog box.
NOTE: Some scanning and destination software might not support all of the
page sizes that the scanner accepts.
NOTE: HP recommends scanning long pages individually at a resolution of 300
dpi or lower.
Reduce file size with hardware compression
The scanner supports multiple levels of JPEG compression to increase the rate of data
transfer from the scanner to the scanning software on the computer. The scanner
compresses the data during the scanning process. The scanning software can
uncompress the data in order to create scanned images. JPEG compression works on
grayscale and color scans.
To enable JPEG compression in an HP Smart Document Scan Software profile, follow
these steps:
1. Open the HP Smart Document Scan Software.
2. Select a scan profile, and then click Edit.
3. Turn on compression:
On the Scan tab of the Profile Settings dialog box, select the Use scanner
compression (for optimal speed) check box.
4. Set how much compression should be performed:
a.On the Scan tab of the Profile Settings dialog box, click Advanced Settings.
b.On the More tab of the Properties dialog box, move the Scanner JPEG
Compression to the value that you want.
NOTE: Use the ISIS or TWAIN user interface to control compression in third-party
software.
Chapter 3
16 Useful scanner features

Other manuals for HP Scanjet 7000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Scanjet 7000 and is the answer not in the manual?

HP Scanjet 7000 Specifications

General IconGeneral
Storage temperature (T-T)-40 - 60 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)0 - 90 %
Operating relative humidity (H-H)15 - 80 %
Package weight10200 g
Sustainability certificatesENERGY STAR
Input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (typical)40 W
DisplayLCD
Scanner typeSheet-fed scanner
Product colorBlack, Silver
Film scanning-
Color scanningYes
Grayscale levels256
Input color depth48 bit
Maximum scan size216 x 864 mm
Output color depth24 bit
ADF scan speed (b/w, A4)40 ppm
ADF scan speed (color, A4)35 ppm
Optical scanning resolution600 x 600 DPI
Duplex ADF scan speed (b/w, A4)80 ipm
Duplex ADF scan speed (color, A4)70 ipm
SafetyIEC 60950-1, CCC, GOST, BSMI, NOM
Minimum scan size50.8 x 73.6mm
Image formats supportedBMP, JPG, PNG, TIF
ISO A-series sizes (A0...A9)A4, A5, A6, A8
Scanning media types supportedCard stock, Envelopes, Plain paper
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight49 - 120 g/m²
Scan toE-mail
Sensor typeCCD
Scan driversISIS, TWAIN, WIA
Scan file formatsBMP, DOC, HTM, JPG, OPF, PDF, PNG, RTF, TIFF, TXT, UNICODE, WPD, XLS, XPS
Daily duty cycle (max)2000 pages
Auto document feeder (ADF) input capacity50 sheets
USB version2.0
Standard interfacesUSB 2.0
Minimum RAM512 MB
Mac compatibilityNo
Minimum processor1.3 GHz
Minimum storage drive space300 MB
Minimum system requirementsUSB 1.1 CD-ROM 1024x768 SVGA
Compatible operating systemsWindows 7 Windows Vista Windows XP Professional (32/64-Bit) Windows XP Media Center Windows XP Home Windows 2000
Windows operating systems supportedWindows 2000, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Electromagnetic compatibilityFCC, CISPR, ANSI, CAN/CSA–CISPR, EN, AS/NZS CISPR, CNS
Weight and Dimensions IconWeight and Dimensions
Depth280 mm
Width320 mm
Height246 mm
Weight7280 g
