HP Slate 2 User Manual

1.
2.
3.
Check latest software/driver release for updates on supported security features.
Maximum output power may vary by country according to local regulations.
Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
HP un2430 EV-DO/HSDPA
Mobile Broadband Module
(Gobi™ 3000)
Technology/Operating
Bands
GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS), 1900MHz
(PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz
(UTRA FDD Band II), AWS (UTRA FDD Band IV), 900MHz(UTRA FDD Band VIII),
850MHz (UTRA FDD Band V)
1xEVDO/1xRTT with receive diversity: 850MHz (Band Class0-Cell), 1900MHz
(Band Class1-PCS)
Wireless Protocol
Standards
GSM/GPRS/EDGE: Class A, Multi-slot class 10 operation, coding schemes CS1 -
CS4 and MSC1 - MSC9.
UMTS/WCDMA: Release 99 and Release 6
CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-856, IS-2000
Wireless Parametric
Standards
Meets or exceeds TIA/EIA IS-98-D
Maximum Data Rates UMTS (HSPA) - 14.4 Mbps (Download ), 5.76Mbps (Upload)
CDMA (EVDO Release A) - 3.1 Mbps (Download), 1.8Mbps (Upload)
GPS Standalone GPS enabled
gpsOneXTRATM™
GPS Bands L1 - 1575.42 MHz
Maximum Output Power GSM/GPRS/EDGE: 32dBm (+/-1)
WCDMA: 24dBm (+0.7/-2.3)
CDMA: 24dBm (+0.7/-2)
Maximum Power
Consumption
2750mA (peak); 1100mA (average)
Power Consumption, Idle
Not Connected
20 mA
Power Management USB selective suspend
Integrated notebook wireless button
Antenna Type Dual high efficiency 5 band antennae with spatial diversity, mounted in the
display enclosure
Form Factor PCI-Express MiniCard, USB 2.0 interface
Weight 11.5 g
Dimensions (Length x
Width x Thickness)
2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)
Voltage, Operating 3.3v +/- 10%
Temperature, Operating
(from TIA/EIA/IS-98-D)
-22° to 158° F (-30° to 70° C) (full RF performance)
-22° to 167° F (-30° to 75° C) (reduced RF performance)
Temperature, Non-
operating, 96 hours (from
MIL-STD 202 Method 108)
-40° to 185° F (-40° to 85° C)
Humidity, Non-operating 95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
QuickSpecs
HP Slate 2 Tablet
Technical Specifications
DA - 14196 North America — Version 8 — June 25, 2012 Page 13

HP Slate 2 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
LED backlight	Yes
Display diagonal	8.9 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	200 cd/m²
Display resolution	1024 x 600 pixels
Display number of colors	16.78 million colors
Tjunction	90 °C
Processor code	SLC2P
Processor cache	0.512 MB
Processor cores	1
System bus rate	- GT/s
Processor family	Intel Atom®
Processor threads	2
Processor codename	Lincroft
Motherboard chipset	Intel SM35 Express
Processor frequency	1.5 GHz
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	13.8x13.8 mm
Processor front side bus	- MHz
Processor operating modes	32-bit
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Design Power (TDP)	3 W
64-bit computing	No
Processor ARK ID	55663
Processor socket	T-PBGA518
Video capture resolution (max)	640 x 480 pixels
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Storage media	SSD
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	32 GB
Graphics card	GMA 600
Maximum graphics card memory	815 MB
Video capturing speed	25 fps
Main camera resolution	2048 x 1536 pixels
Maximum video resolution	1024 x 768 pixels
Second camera resolution	0.3 MP
Main camera resolution (numeric)	3 MP
Audio system	SRS Premium Sound
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Form factor	Slate
Product color	Black, Silver
Platform	Windows
Operating system version	Professional
Operating system installed	Windows 7 Professional
Battery capacity	30 Wh
Battery life (max)	7.5 h
AC adapter power	30 W
AC adapter frequency	47/63 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	RoHS

Weight and Dimensions

Depth	15 mm
Width	234 mm
Height	150 mm
Weight	690 g
