HP Slate 2 User Manual

Configuration Utilities HP Connection Manager
LED Activity LED Off - Radio Off;
Solid LED On - Radio On
Environmental Data Eco-Label Certifications This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
System Configuration The configuration used for the Energy Consumption and Declared Noise
Emissions data for these models are based on a "Typically Configured
Notebook"
Energy Consumption 115 VAC 230 VAC 100 VAC
Normal Operation 3.15 W 3.27 W 3.03 W
Sleep N/A N/A N/A
Off N/A N/A N/A
Heat Dissipation * 115 VAC 230 VAC 100 VAC
Normal Operation 11 BTU/hr 11 BTU/hr 10 BTU/hr
Sleep N/A N/A N/A
Off N/A N/A N/A
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle 2.6 15.6
Fixed Disk
(random writes)
2.6 15.4
System fan is usually off except when charging the battery
Batteries This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the 5ppm by weight
Cadmium greater than 10ppm by weight
The battery type and chemistry used in the product is:
CR2032 (coin cell), Li-ion
6-cell high capacity Lithium-Ion battery (optional 8 cell available)
Additional
information
This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive – 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and Electronic
QuickSpecs
HP Slate 2 Tablet
Technical Specifications
DA - 14196 North America — Version 8 — June 25, 2012 Page 14

HP Slate 2 Specifications

General

Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
LED backlight	Yes
Display diagonal	8.9 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	200 cd/m²
Display resolution	1024 x 600 pixels
Display number of colors	16.78 million colors
Tjunction	90 °C
Processor code	SLC2P
Processor cache	0.512 MB
Processor cores	1
System bus rate	- GT/s
Processor family	Intel Atom®
Processor threads	2
Processor codename	Lincroft
Motherboard chipset	Intel SM35 Express
Processor frequency	1.5 GHz
Processor lithography	45 nm
Processor manufacturer	Intel
Processor package size	13.8x13.8 mm
Processor front side bus	- MHz
Processor operating modes	32-bit
Supported instruction sets	SSE2, SSE3, SSSE3
Thermal Design Power (TDP)	3 W
64-bit computing	No
Processor ARK ID	55663
Processor socket	T-PBGA518
Video capture resolution (max)	640 x 480 pixels
Internal memory	2 GB
Memory clock speed	800 MHz
Internal memory type	DDR2-SDRAM
Storage media	SSD
Compatible memory cards	SD, SDHC, SDXC
Internal storage capacity	32 GB
Graphics card	GMA 600
Maximum graphics card memory	815 MB
Video capturing speed	25 fps
Main camera resolution	2048 x 1536 pixels
Maximum video resolution	1024 x 768 pixels
Second camera resolution	0.3 MP
Main camera resolution (numeric)	3 MP
Audio system	SRS Premium Sound
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Form factor	Slate
Product color	Black, Silver
Platform	Windows
Operating system version	Professional
Operating system installed	Windows 7 Professional
Battery capacity	30 Wh
Battery life (max)	7.5 h
AC adapter power	30 W
AC adapter frequency	47/63 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	RoHS

Weight and Dimensions

Depth	15 mm
Width	234 mm
Height	150 mm
Weight	690 g
