HP sprocket User Manual

9
3
1
4
5
7
1
6
8
2
Supplied Items
HP Sprocket Photo Printer
Setup Card
HP ZINK® Sticky-Backed Photo Paper (10 sheets)
USB charging cable
Regulatory Information Sheet
Product Overview
1. Power Button
2. Status Indicator LED Light
3. Charging Indicator LED Light
4. Charging Port
5. Reset Button
6. Top Cover
7. Paper Output Slot
8. Paper Input Tray
(not visible from exterior)
9. Lanyard Notch
LED Indicator Lights: Status Indicator and Charging Indicator
LED Color HP Sprocket Condition Description
White
Right LED indicator
Idle/On Powered on and waiting for print job. Device
defaults to power down after 5 minutes without
use. This can be changed in the sprocket menu.
Red
Left LED indicator
Charging Connected to power. LED will turn green upon full
charge. Printer can be used while charging.
Green
Left LED indicator
Fully charged Device is fully charged.
White, Blinking
Right LED indicator
Powering on/Receiving print
job
LED ashes white when powering on and when
receiving a print job.
Red, Blinking
Right LED indicator
Printer error When a print error occurs, the LED will ash red.
Wait for the light to turn white to send a print job.
Parts and Controls

HP sprocket Specifications

General

Type	Mobile printer
Color	Yes
Print technology	ZINK (Zero ink)
Maximum resolution	313 x 400 DPI
PictBridge	No
USB connector	Micro-USB Type-B
Bluetooth version	3.0+HS
Connectivity technology	Wireless
Product color	Black
Internal memory	512 MB
Market positioning	Home & office
Mobile operating systems supported	Android, iOS
Battery type	500 mAh
Paper dimensions	2 x 3\
Battery voltage	7.4 V
Power source type	Battery
Battery recharge time	1.5 h
Power consumption (printing)	15.91 W
Cables included	Micro-USB
Bundled software	HP Sprocket app
Print speed	40 s
Maximum print size	2\

Weight and Dimensions

Depth	75 mm
Width	116 mm
Height	23 mm
