HP t5740 - Thin Client - Installing PCI Express Module and Card; External Drives Installation

6. Replace the access plate:
Figure 2-12 Replacing the SO-DIMM access plate
a. Insert the tab on the front edge into its slot and set the plate into position.
NOTE: You may need to press lightly on the access plate to position it properly against the
chassis.
b. Replace the two screws to secure the access plate to the chassis.
7. Slide the serial number tab into its slots.
Installing the PCI Express Expansion Module and PCI Express Card
Before beginning the replacement process, review General Hardware Installation Sequence
on page 12 for procedures you should follow before and after installing or replacing hardware.
WARNING! Before removing the side access panel, ensure that the thin client is turned off and the
power cord is disconnected from the electrical outlet.
Follow the installation instructions included in the PCIe Expansion Module option kit.
External Drives
Various external USB drives are available as options for the t5740/t5745. For more information about
these drives, visit
http://h10010.www1.hp.com/wwpc/us/en/sm/WF12a/12454-12454-321959.html, or
refer to the instructions that accompany the option.
For more information about available options, visit the HP Web site at
http://h10010.www1.hp.com/
wwpc/us/en/sm/WF12a/12454-12454-321959.html.
ENWW Installing Thin Client Options 23
